Audiophile vinyl enjoyment because pure silver offers crystal clear performance!

2M series uses Ortofons own technology, that allows to reach the same levels of flat frequency response as Moving Coil cartridges. 2M Silver combines these technologies with ultimate simple mounting procedure for nearly all available turntables. Due to MM principle, 2M cartridges are compatible with most phono preamplifiers. An absolutely feature unique in this price range, 2M-Silver uses internal silver plated copper coils, which guarantees outstanding sonic results!

Features

• Moving Magnet principle
• Silver plated copper coils windings to achieve higher quality and more dynamic playback compared with conventional MM cartridges
• Suitable for low to medium tonearm masses
• 1/2 inch mounting standard
• High trackability
• 2M-Silver should be connected to phono MM inputs
• As with most MM cartridges, stylus may be exchanged

Technical Specifications

Cartridge principle:  MM (Moving-Magnet)

Output voltage at 1 kHz:  4 mV

Channel separation at 1 kHz:  22 dB

Tracking ability at 315Hz:  70 μm

Frequency response:  20 - 20 000 Hz +/- 2dB

Stylus type:  Elliptical

Stylus tip radius:  r/R 8/18 μm

Tracking force, range:  1,8 - 2,2 g (mN)

Tracking force, recommended:  2,0 g (mN)

Height stylus tip to top mounting surface:   18 mm

Tracking angle:  20°

Internal impedance, DC resistance:  750 Ohm

Internal inductance:  450mH

Recommended load resistance:  47kOhm

Recommended load capacitance:  150-300pF

Cartriddge weight:  7,2 g

• Manufacturer : Pro_ject
• Supplier Code : 1940 877003
