Cleanest power for ultimate sound!

The power supply is a very important part of the audio path and significantly contributes to the sonic quality of an audio product. With the new Power Box RS2 Sources you can connect up to four 20V RS/RS2 devices and benefit from the perfect power contribution. Four standard mini XLR to mini XLR connection cables are included in the packaging.

A linear power supply consists of a massive toroidal transformer, which avoids penetration of interferences from mains into the audio component. The built-in transformer has a much higher power reserve compared to the standard power adapter. It has very low output impedance and in combination with large filtration capability it can easily manage all power needs. Sound staging, darkness of silent backgrounds and small detail resolution will improve strongly and contribute to a far better overall performance of each component.

Power Box RS2 Sources is made in Europe and available in a black or silver full aluminium housing.

Powers four 20 V RS / RS2 devices

One power supply for all source components

Improved soundstage and detail resolution

Cleanest power using non switching power supply

Soft start system avoids current inrush

Audio grade toroidal transformer

Main isolating transformer with copper foil shielding

Secondary voltage rectification with precise regulation

High filtration capacity 10,000 µF

Low ESR capacitors

Low noise components with surge protection

Rigid aluminium casing protects against interference

Available in silver or black

Made in Europe

Input voltage 115 V / 230 V AC

Output voltage / current 4 x 20 V ±0.5% / 2 A

Ripple max 6 mV peak to peak

Filtration capacity 10,000 µF

Included accessories 4 x mini XLR to mini XLR connection cables

Dimensions W x H x D 206 x 71 x 209 mm

Weight 3550 g

• Manufacturer : Pro_ject
• Supplier Code : 222 92662
