Shanling ONIX Alpha Xi1 (5060978090057)
Excellent Sound in Smallest Package.
Το ζεύγος των κορυφαίων DAC της Cirrus Logic CS43198 παρέχει εξαιρετικά καθαρό ήχο, ενώ παράλληλα παρέχει τη μοναδική μας ρύθμιση ήχου. Λειτουργούν σε πλήρως ισορροπημένη ρύθμιση, τροφοδοτώντας δύο αποκλειστικούς ενισχυτές ακουστικών SGM8262, προσφέροντας ισχύ εξόδου έως και 500 mW @ 32 Ohm. Μετατρέποντας το ONIX XI1 σε ένα πραγματικά ισχυρό μικροσκοπικό θηρίο, που οδηγεί οτιδήποτε, από ευαίσθητα IEM έως απαιτητικά πλήρους μεγέθους Planars.
We support installment purchases using a debit card. For details call us Phone
After Sales Support
Supplier guarantee up toYears
Next to you since 1976
Over 46 years of experience!
Join us
Earn special offers
Excellent Sound in Smallest Package
Pair of top-of-the-line Cirrus Logic CS43198 DACs provide exquisitely clean sound, while still providing our unique sound tuning. Running in a fully balanced setup, feeding two dedicated SGM8262 headphone amplifiers, offering up to 500 mW @ 32 Ohm output power. Making ONIX XI1 into a truly powerful tiny beast, driving anything from sensitive IEMs to demanding full-size Planars.
Advanced Control
ONIX XI1 offers a 0.87-inch monochromatic screen for quick access to a range of settings directly on the device, without any need to dive into a companion app and compatible with an unlimited range of systems. A trio of hardware buttons then provide quick and tactile control over volume and playback.
Traditional Look Minimized
Even our smallest DAC follows traditional standards of ONIX design and build quality. Deep black combined with golden yellow elements, in sturdy body combining elaborately machined aluminium, glass and smooth fake leather back.
Advanced Control
ONIX XI1 offers a 0.87-inch monochromatic screen for quick access to a range of settings directly on the device, without any need to dive into a companion app and compatible with an unlimited range of systems. A trio of hardware buttons then provide quick and tactile control over volume and playback.
Traditional Look Minimized
Even our smallest DAC follows traditional standards of ONIX design and build quality. Deep black combined with golden yellow elements, in sturdy body combining elaborately machined aluminium, glass and smooth fake leather back.
Specification
Dimensions: 64 x 32 x14 mm
Weight: 38g
Hi-Res Support: 32bit / 768kHz & DSD256
Gain: Low & High Gain
Display: 0.87-Inch Monochromatic
Controls: 3 Hardware Multifunctional Buttons
Input: Standard USB-C Connector
Compatibility: Android & iOS Devices, Windows & Mac Computers
* For devices using Lightning Connector, please purchase Shanling L3 cable
3.5mm Single-Ended Output
Output Power: 2.4V@32Ω (180mW@32Ω)
Output Impedance: 0.4Ω
4.4mm Balanced Output
Output Power: 4.0V@32Ω (500mW@32Ω)
THD+N: 0.0005% @32Ω (A-Weight)
Dynamic Range: 129dB @32Ω (A-Weight)
Channel Separation: 99dB
Signal-to-Noise Ratio : 129dB @32Ω (A-Weight)
Output Impedance: 0.8Ω
