The Table:

• 1.25”" thick textured vinyl covered non-resonant MDF chassis.

• 16" x 11" footprint

• 19” x 14” x6” overall size

• Aluminum Platter

• Platter rotates on an oil bath bearing and fitted to shaft with a #2 Jacob’s Taper for a concentric rigidly mounted coupling.

• The bearing has a PEEK thrust disc and machined graphite impregnated brass bushings using a Thompson Engineering 60 Rockwell case hardened shaft.

Tonearm:

• New 9” vertical Yoke type tonearm with lateral turntable type bearing.

• Pivot to spindle: 223mm

• Effective length: 240.7mm

• Overhang: 17.7mm

• Offset angle: 22.85 degrees

• Average RMS distortion: .36%

• VTA adjustable arm mount.

• Damped stainless steel armtube.

• Very pure copper wire, twisted with special insulating jacket.

• The armbase is upgradeable to a standard JMW 9 arm.

Additional Specifications:

Type                              Belt drive (manual turntable)

Motor                            24v synchronous AC motor

Turntable Platter         Aluminum

Diameter                      11.81” (30.0 cm)

Turntable Speeds        33.3 RPM and 45 RPM

Wow and Flutter           .1% WRMS (in accordance with DIN specification)

Rumble                         < - 80dB (IEC 98A unweighted)

Cartridge                      Ortofon 2M Red

Output                          5 mV @ 1 KHz

Tracking Force             1.5 grams (recommended)

Input Load                   47K

Weight                          5.5 grams

Power Supply              110v VAC @ 60 Hz, 230v VAC @ 50hz

Power Consumption  7.7 watts at full output

Dimensions                 18.5” (470 mm) W x 13.5” (343 mm) D x 4.3” (109 mm)H

Weight                          12.9 lbs. (5.9 kg)

• Manufacturer : VPI
• Color : Καφέ
