SKU: 1800118
Ortofon STYLUS GOLD
The Stylus Gold is a top model with gold plating and features a Special Pro Elliptical diamond and an output voltage of 6 mV.
Διαθέσιμο στην αποθήκη - Αποστολή / Παραλαβή σε 4-10 εργάσιμες μέρες
€89,00
Final Price
Add to cart
Do you have any questions or want to place a phone order?
Call us at 2109401167
Buy Now Pay Later with the use of a debit card
Details
We support installment purchases using a debit card. For details call us Phone
Enter your postal code so we can inform you about shipping/delivery options.
After Sales Support
Supplier guarantee up toYears
Next to you since 1976
Over 46 years of experience!
Join us
Earn special offers
The Stylus Gold is a top model with gold plating and features a Special Pro Elliptical diamond and an output voltage of 6 mV.
Channel balance at 1 kHz 1,5 dB
Output voltage at 1 kHz, 5cm/sec 6 mV
Channel separation at 1 kHz 23 dB
Tracking ability at 315 Hz 80 μm
Compliance, dynamic, lateral 7 μm/m N
Stylus type Special Elliptical
Stylus tip radius r/R 13/25 μm
Tracking force range 2.0-5.0 g (20-50 mN)
Tracking force, recommended 3.0 g (30 mN)
Tracking angle 20°
Internal impedance, DC resistance 750 Ohm
Cartridge weight 1 g
Recommended load resistance 47 kOhm
Internal inductance 450 mH
Recommended load capacitance 200-600 pF
